隔離式洗脫機

隔離式洗脫機

●本公司新研制的GL系列隔離式洗衣脫水機,能嚴格的無菌、無塵、防靜電洗滌要求。通過隔離式洗衣機和隔離墻將洗衣機和隔離墻將洗衣房分成“潔凈區”和“操作區”兩個立的操作區間。洗滌物由位于“操作區”一側的裝料門裝入,洗滌完畢后從位于“潔凈區”一側的卸料門取出,加上潔凈空氣控制系統的作用,可防止細菌和塵埃顆粒從“操作區”流向“潔凈區”,從而避免潔凈物的二次污染和交叉感染。
洗滌設備
 功能點Feature and functions
●本公司新研制的GL系列隔離式洗衣脫水機,能嚴格的無菌、無塵、防靜電洗滌要求。通過隔離式洗衣機和隔離墻將洗衣機和隔離墻將洗衣房分成“潔凈區”和“操作區”兩個立的操作區間。洗滌物由位于“操作區”一側的裝料門裝入,洗滌完畢后從位于“潔凈區”一側的卸料門取出,加上潔凈空氣控制系統的作用,可防止細菌和塵埃顆粒從“操作區”流向“潔凈區”,從而避免潔凈物的二次污染和交叉感染。
●GL系列隔離式洗衣機技術進、結構合理、運行經濟、維護方便、性能良,廣泛用于、食品、生物制藥、核電站等環境有嚴格無塵、無菌要求的洗衣房,是洗衣服的理想洗滌設備。

●Our company newly  developed GL-series isolated-type washers, which are able to meet strict sterile, dust-free, antstatic cleaning requirements. Laundry is divided into “clean zone ”and“operating area”of two separate operating ranges through isolated-type washer and isolation wall. Launderettes will be loaded into the washing machine through the loading door from the“operating area”. When washing is completed, wunder will be carried out form the“clean  zone ”. With clean air control system, It will prevent bacteria and dust particles from the“operating area”to“clean zone”, this avoiding secondary pollution of clean washing and cross-infection.
●The  company produces  GL-series isolated-type washers, with advanced technology, reasonable structure, economic operation, convenient maintenance and excellent performance, are  widely used in hospitals, food, biopharmaceutical, nuclear power plants where extremely strict dust and bacteri -afree environment sure being observed.

技術參數Technical parameters


          型號 model
項目 item
單位/unit GL30 GL50 GL70 GL100
額定洗滌量 max capacity kg 30 50 70 100
外形尺寸 appearance size
height mm 1820 1820 1980 2050
width mm 1320 1720 1520 1720
depth mm 1100 1100 1500 1550
滾筒轉速洗滌,均勻,中脫,脫轉速根據需要由變頻器設定 。
Drum rotation(r/min) washing even spread medium dewatering.  Fast rotation limit set by vfd.
電機功率 electric power KW 4 5.5 7.5 7.5
接口尺寸 interfaced
冷水進水口 cold water inlet inch 1'' 1'' 1'' 1''
熱水進水口 hot water inlet inch 1'' 1'' 1'' 1''
蒸汽接口 steam interface inch 1/2'' 3/4'' 1'' 1''
排水口 drain inch 3'' 3'' 4'' 4''
重量 weight kg 1110 1340 1920 3200
